Wt
3.7.1
|
A single node in a tree. More...
#include <Wt/WTreeNode>
Public Types | |
enum | LoadPolicy { LazyLoading, PreLoading, NextLevelLoading } |
An enumeration for the policy to load children. More... | |
enum | ChildCountPolicy { Disabled, Enabled, Lazy } |
An enumeration for the policy to display the child count. More... | |
![]() | |
typedef void(WObject::* | Method) () |
Typedef for a WObject method without arguments. | |
Public Member Functions | |
WTreeNode (const WString &labelText, WIconPair *labelIcon=0, WTreeNode *parentNode=0) | |
Creates a tree node with the given label. More... | |
~WTreeNode () | |
Destructor. | |
virtual WTree * | tree () const |
Returns the tree. More... | |
WText * | label () const |
Returns the label. | |
WIconPair * | labelIcon () const |
Returns the label icon. | |
void | setLabelIcon (WIconPair *labelIcon) |
Sets the label icon. | |
virtual void | insertChildNode (int index, WTreeNode *node) |
Inserts a child node. More... | |
void | addChildNode (WTreeNode *node) |
Adds a child node. More... | |
void | removeChildNode (WTreeNode *node) |
Removes a child node. More... | |
const std::vector< WTreeNode * > & | childNodes () const |
Returns the list of children. | |
virtual int | displayedChildCount () const |
Returns the number of children that should be displayed. More... | |
void | setChildCountPolicy (ChildCountPolicy policy) |
Configures how and when the child count should be displayed. More... | |
ChildCountPolicy | childCountPolicy () const |
Returns the child count policy. More... | |
void | setImagePack (const std::string &url) |
Sets the image pack for this (sub)tree (deprecated). More... | |
void | setLoadPolicy (LoadPolicy loadPolicy) |
Sets the load policy for this tree. More... | |
bool | isExpanded () const |
Returns whether this node is expanded. | |
void | setSelectable (bool selectable) |
Allows this node to be selected. More... | |
virtual bool | isSelectable () const |
Returns if this node may be selected. More... | |
WTreeNode * | parentNode () const |
Returns the parent node. More... | |
void | setNodeVisible (bool visible) |
Sets the visibility of the node itself. More... | |
void | setChildrenDecorated (bool decorated) |
Sets whether this node's children are decorated. More... | |
void | setInteractive (bool interactive) |
Sets whether this node is interactive. More... | |
void | expand () |
Expands this node. More... | |
void | collapse () |
Collapses this node. More... | |
EventSignal< WMouseEvent > & | expanded () |
Signal emitted when the node is expanded by the user. More... | |
EventSignal< WMouseEvent > & | collapsed () |
Signal emitted when the node is collapsed by the user. More... | |
Signal< bool > & | selected () |
Signal that is emitted when the node is added or removed from the selection More... | |
![]() | |
WCompositeWidget (WContainerWidget *parent=0) | |
Creates a WCompositeWidget. More... | |
WCompositeWidget (WWidget *implementation, WContainerWidget *parent) | |
Creates a WCompositeWidget with given implementation. More... | |
virtual void | setObjectName (const std::string &name) |
Sets an object name. More... | |
virtual std::string | objectName () const |
Returns the object name. More... | |
virtual const std::string | id () const |
Returns the (unique) identifier for this object. More... | |
virtual void | setPositionScheme (PositionScheme scheme) |
Sets the CSS position scheme. More... | |
virtual PositionScheme | positionScheme () const |
Returns the CSS position scheme. More... | |
virtual void | setOffsets (const WLength &offset, WFlags< Side > sides=All) |
Sets CSS offsets for a non-statically positioned widget. More... | |
virtual WLength | offset (Side s) const |
Returns a CSS offset. More... | |
virtual void | resize (const WLength &width, const WLength &height) |
Resizes the widget. More... | |
virtual WLength | width () const |
Returns the width. More... | |
virtual WLength | height () const |
Returns the height. More... | |
virtual void | setMinimumSize (const WLength &width, const WLength &height) |
Sets a minimum size. More... | |
virtual WLength | minimumWidth () const |
Returns the minimum width. More... | |
virtual WLength | minimumHeight () const |
Returns the minimum height. More... | |
virtual void | setMaximumSize (const WLength &width, const WLength &height) |
Sets a maximum size. More... | |
virtual WLength | maximumWidth () const |
Returns the maximum width. More... | |
virtual WLength | maximumHeight () const |
Returns the maximum height. More... | |
virtual void | setLineHeight (const WLength &height) |
Sets the CSS line height for contained text. | |
virtual WLength | lineHeight () const |
Returns the CSS line height for contained text. More... | |
virtual void | setFloatSide (Side s) |
Specifies a CSS float side. More... | |
virtual Side | floatSide () const |
Returns the CSS float side. More... | |
virtual void | setClearSides (WFlags< Side > sides) |
Sets the sides that should be cleared of floats. More... | |
virtual WFlags< Side > | clearSides () const |
Returns the sides that should remain empty. More... | |
virtual void | setMargin (const WLength &margin, WFlags< Side > sides=All) |
Sets CSS margins around the widget. More... | |
virtual WLength | margin (Side side) const |
Returns a CSS margin set. More... | |
virtual void | setHiddenKeepsGeometry (bool enabled) |
Sets whether the widget keeps its geometry when hidden. More... | |
virtual bool | hiddenKeepsGeometry () const |
Returns whether the widget keeps its geometry when hidden. More... | |
virtual void | setHidden (bool hidden, const WAnimation &animation=WAnimation()) |
Hides or shows the widget. More... | |
virtual bool | isHidden () const |
Returns whether the widget is set hidden. More... | |
virtual bool | isVisible () const |
Returns whether the widget is visible. More... | |
virtual void | setDisabled (bool disabled) |
Sets whether the widget is disabled. More... | |
virtual bool | isDisabled () const |
Returns whether the widget is set disabled. More... | |
virtual bool | isEnabled () const |
Returns whether the widget is enabled. More... | |
virtual void | setPopup (bool popup) |
Lets the widget overlay over other sibling widgets. More... | |
virtual bool | isPopup () const |
Returns whether the widget is overlayed. More... | |
virtual void | setInline (bool isInline) |
Sets whether the widget is displayed inline or as a block. More... | |
virtual bool | isInline () const |
Returns whether the widget is displayed inline or as block. More... | |
virtual void | setDecorationStyle (const WCssDecorationStyle &style) |
Sets a CSS decoration style. More... | |
virtual WCssDecorationStyle & | decorationStyle () |
Returns the decoration style of this widget. More... | |
virtual void | setStyleClass (const WString &styleClass) |
Sets (one or more) CSS style classes. More... | |
virtual WString | styleClass () const |
Returns the CSS style class. More... | |
virtual void | addStyleClass (const WString &styleClass, bool force=false) |
Adds a CSS style class. More... | |
virtual void | removeStyleClass (const WString &styleClass, bool force=false) |
Removes a CSS style class. More... | |
virtual bool | hasStyleClass (const WString &styleClass) const |
Returns whether the widget has a style class. | |
virtual void | setVerticalAlignment (AlignmentFlag alignment, const WLength &length=WLength::Auto) |
Sets the vertical alignment. More... | |
virtual AlignmentFlag | verticalAlignment () const |
Returns the vertical alignment. More... | |
virtual WLength | verticalAlignmentLength () const |
Returns the fixed vertical alignment that was set. More... | |
virtual void | setToolTip (const WString &text, TextFormat textFormat=PlainText) |
Sets a tooltip. More... | |
virtual WString | toolTip () const |
Returns the tooltip. | |
virtual void | setDeferredToolTip (bool enable, TextFormat textFormat=PlainText) |
Enable deferred tooltip. More... | |
virtual void | refresh () |
Refresh the widget. More... | |
virtual void | setAttributeValue (const std::string &name, const WString &value) |
Sets an attribute value. More... | |
virtual WString | attributeValue (const std::string &name) const |
Returns an attribute value. More... | |
virtual void | setJavaScriptMember (const std::string &name, const std::string &value) |
Sets a JavaScript member. More... | |
virtual std::string | javaScriptMember (const std::string &name) const |
Returns the value of a JavaScript member. More... | |
virtual void | callJavaScriptMember (const std::string &name, const std::string &args) |
Calls a JavaScript member. More... | |
virtual void | load () |
Loads content just before the widget is used. More... | |
virtual bool | loaded () const |
Returns whether this widget has been loaded. More... | |
virtual void | setCanReceiveFocus (bool enabled) |
Sets whether the widget can receive focus. More... | |
virtual bool | canReceiveFocus () const |
Returns whether the widget can receive focus. More... | |
virtual void | setFocus (bool focus) |
Sets focus. More... | |
virtual bool | setFirstFocus () |
Set focus on the widget's first descendant. More... | |
virtual bool | hasFocus () const |
Returns whether the widget currently has the focus. | |
virtual void | setTabIndex (int index) |
Sets the tab index. More... | |
virtual int | tabIndex () const |
Returns the tab index. More... | |
virtual void | setId (const std::string &id) |
Sets the CSS Id. More... | |
virtual WWidget * | find (const std::string &name) |
Finds a descendent widget by name. More... | |
virtual WWidget * | findById (const std::string &name) |
Finds a descendent widget by id. | |
virtual void | doJavaScript (const std::string &js) |
Executes the given JavaScript statements when the widget is rendered or updated. More... | |
virtual void | propagateSetEnabled (bool enabled) |
Propagates that a widget was enabled or disabled through children. More... | |
virtual bool | scrollVisibilityEnabled () const WT_CXX11ONLY(final override) |
Returns whether scroll visibility detection is enabled for this widget. More... | |
virtual void | setScrollVisibilityEnabled (bool enabled) WT_CXX11ONLY(final override) |
Sets whether scroll visibility detection is enabled for this widget. More... | |
virtual int | scrollVisibilityMargin () const WT_CXX11ONLY(final override) |
Returns the margin around the viewport within which the widget is considered visible. More... | |
virtual void | setScrollVisibilityMargin (int margin) WT_CXX11ONLY(final override) |
Sets the margin around the viewport within which the widget is considered visible. More... | |
virtual Signal< bool > & | scrollVisibilityChanged () WT_CXX11ONLY(final override) |
Signal triggered when the scroll visibility of this widget changes. More... | |
virtual bool | isScrollVisible () const WT_CXX11ONLY(final override) |
Returns whether this widget is currently considered scroll visible. More... | |
virtual void | setThemeStyleEnabled (bool enabled) |
Sets whether theme styling for a widget is enabled or disabled. More... | |
virtual bool | isThemeStyleEnabled () const |
Returns whether this widget is currently styled by the chosen theme. More... | |
![]() | |
virtual | ~WWidget () |
Destructor. More... | |
WWidget * | parent () const |
Returns the parent widget. More... | |
virtual void | removeChild (WObject *child) |
Removes a child object. More... | |
void | setWidth (const WLength &width) |
Sets the width. More... | |
void | setHeight (const WLength &height) |
Sets the height. More... | |
virtual void | positionAt (const WWidget *widget, Orientation orientation=Vertical) |
Positions a widget next to another widget. More... | |
virtual void | toggleStyleClass (const WString &styleClass, bool add, bool force=false) |
Toggles a CSS style class. | |
std::string | jsRef () const |
Returns a JavaScript expression to the corresponding DOM node. More... | |
void | setFocus () |
Sets focus. More... | |
virtual void | acceptDrops (const std::string &mimeType, const WString &hoverStyleClass=WString()) |
Sets a mime type to be accepted for dropping. More... | |
virtual void | stopAcceptDrops (const std::string &mimeType) |
Indicates that a mime type is no longer accepted for dropping. More... | |
virtual void | htmlText (std::ostream &out) |
Streams the (X)HTML representation. More... | |
bool | isRendered () const |
Returns whether the widget is rendered. More... | |
void | hide () |
Hides the widget. More... | |
void | animateHide (const WAnimation &animation) |
Hides the widget using an animation. More... | |
void | show () |
Shows the widget. More... | |
void | animateShow (const WAnimation &animation) |
Shows the widget using an animation. More... | |
void | enable () |
Enables the widget. More... | |
void | disable () |
Disable thes widget. More... | |
bool | layoutSizeAware () const |
Returns whether the widget is layout size aware. More... | |
![]() | |
WObject (WObject *parent=0) | |
Create a WObject with a given parent object. More... | |
virtual | ~WObject () |
Destructor. More... | |
void | resetLearnedSlots () |
Resets learned stateless slot implementations. More... | |
template<class T > | |
void | resetLearnedSlot (void(T::*method)()) |
Resets a learned stateless slot implementation. More... | |
template<class T > | |
WStatelessSlot * | implementStateless (void(T::*method)()) |
Declares a slot to be stateless and learn client-side behaviour on first invocation. More... | |
template<class T > | |
WStatelessSlot * | implementStateless (void(T::*method)(), void(T::*undoMethod)()) |
Declares a slot to be stateless and learn client-side behaviour in advance. More... | |
void | isNotStateless () |
Marks the current function as not stateless. More... | |
template<class T > | |
WStatelessSlot * | implementJavaScript (void(T::*method)(), const std::string &jsCode) |
Provides a JavaScript implementation for a method. More... | |
void | addChild (WObject *child) |
Adds a child object. More... | |
const std::vector< WObject * > & | children () const |
Returns the children. | |
WObject * | parent () const |
Returns the parent object. | |
Protected Member Functions | |
WTreeNode (WTreeNode *parentNode=0) | |
Creates a tree node with empty labelArea(). More... | |
WContainerWidget * | labelArea () |
Accesses the container widget that holds the label area. More... | |
virtual void | populate () |
Populates the node dynamically on loading. More... | |
bool | populated () const |
Returns whether this node has already been populated. More... | |
virtual bool | expandable () |
Returns whether this node can be expanded. More... | |
virtual void | renderSelected (bool selected) |
Renders the node to be selected. More... | |
std::string | imagePack () const |
The image pack that is used for this tree node (deprecated). More... | |
virtual void | descendantRemoved (WTreeNode *node) |
Reacts to the removal of a descendant node. More... | |
virtual void | descendantAdded (WTreeNode *node) |
Reacts to the addition of a descendant node. More... | |
virtual void | doExpand () |
The actual expand. More... | |
virtual void | doCollapse () |
The actual collapse. More... | |
virtual void | undoDoExpand () |
Undo method for doCollapse() stateless implementation. More... | |
virtual void | undoDoCollapse () |
Undo method for doCollapse() stateless implementation. More... | |
WIconPair * | expandIcon () const |
Accesses the icon pair that allows expansion of the tree node. | |
![]() | |
virtual void | enableAjax () |
Progresses to an Ajax-enabled widget. More... | |
void | setImplementation (WWidget *widget) |
Set the implementation widget. More... | |
WWidget * | implementation () |
Get the implementation widget. More... | |
virtual int | boxPadding (Orientation orientation) const |
Returns the widget's built-in padding. More... | |
virtual int | boxBorder (Orientation orientation) const |
Returns the widget's built-in border width. More... | |
virtual void | render (WFlags< RenderFlag > flags) |
Renders the widget. More... | |
![]() | |
void | setLayoutSizeAware (bool sizeAware) |
Sets the widget to be aware of its size set by a layout manager. More... | |
virtual void | layoutSizeChanged (int width, int height) |
Virtual method that indicates a size change. More... | |
WWidget (WContainerWidget *parent=0) | |
Creates a widget. More... | |
virtual void | dropEvent (WDropEvent dropEvent) |
Handles a drop event. More... | |
void | scheduleRender (WFlags< RepaintFlag > flags=0) |
Schedules rerendering of the widget. More... | |
virtual WStatelessSlot * | getStateless (Method method) |
On-demand stateless slot implementation. More... | |
Additional Inherited Members | |
![]() | |
static WString | tr (const char *key) |
Short hand for WString::tr() More... | |
![]() | |
static WObject * | sender () |
Returns the sender of the current slot call. More... | |
A single node in a tree.
A tree list is constructed by combining several tree node objects in a tree hierarchy, by passing the parent tree node as the last argument in the child node constructor, or by using addChildNode(), to add a child to its parent.
Each tree node has a label, and optionally a label icon pair. The icon pair offers the capability to show a different icon depending on the state of the node (expanded or collapsed). When the node has any children, a child count may be displayed next to the label using setChildCountPolicy().
Expanding a tree node it will collapse all its children, so that a user may collapse/expand a node as a short-cut to collapsing all children.
The treenode provides several policies to communicate the current contents of the tree to the client (if possible):
The default policy is WTreeNode::LazyLoading. Another load policy may be specified using setLoadPolicy() on the root node and before adding any children. The load policy is inherited by all children in the tree.
There are a few scenarios where it makes sense to specialize the WTreeNode class. One scenario is create a tree that is populated dynamically while browsing. For this purpose you should reimplement the populate() method, whose default implementation does nothing. This method is called when 'loading' the node. The exact moment for loading a treenode depends on the LoadPolicy.
A second scenario that is if you want to customize the look of the tree label (see labelArea()) or if you want to modify or augment the event collapse/expand event handling (see doExpand() and doCollapse()).
See WTree for a usage example.
Wt::WTreeNode::WTreeNode | ( | const WString & | labelText, |
WIconPair * | labelIcon = 0 , |
||
WTreeNode * | parentNode = 0 |
||
) |
Creates a tree node with the given label.
The labelIcon, if specified, will appear just before the label and its state reflect the expand/collapse state of the node.
The node is initialized to be collapsed.
|
protected |
Creates a tree node with empty labelArea().
This tree node has no label or labelicon, and is therefore ideally suited to provide a custom look.
void Wt::WTreeNode::addChildNode | ( | WTreeNode * | node | ) |
Adds a child node.
Equivalent to:
ChildCountPolicy Wt::WTreeNode::childCountPolicy | ( | ) | const |
Returns the child count policy.
void Wt::WTreeNode::collapse | ( | ) |
Collapses this node.
EventSignal< WMouseEvent > & Wt::WTreeNode::collapsed | ( | ) |
Signal emitted when the node is collapsed by the user.
|
protectedvirtual |
Reacts to the addition of a descendant node.
Reimplement this method if you wish to react on the addition of a descendant node. The default implementation simply propagates the event to the parent.
|
protectedvirtual |
Reacts to the removal of a descendant node.
Reimplement this method if you wish to react on the removal of a descendant node. The default implementation simply propagates the event to the parent.
|
virtual |
Returns the number of children that should be displayed.
This is used to display the count in the count label. The default implementation simply returns childNodes().size().
|
protectedvirtual |
The actual collapse.
This method, which is implemented as a stateless slot, performs the actual collapse of the node.
You may want to reimplement this function (and undoDoCollapse()) if you wish to do additional things on node expansion.
|
protectedvirtual |
The actual expand.
This method, which is implemented as a stateless slot, performs the actual expansion of the node.
You may want to reimplement this function (and undoDoExpand()) if you wish to do additional things on node expansion.
void Wt::WTreeNode::expand | ( | ) |
Expands this node.
Besides the actual expansion of the node, this may also trigger the loading and population of the node children, or of the children's children.
|
protectedvirtual |
Returns whether this node can be expanded.
The default implementation populates the node if necessary, and then checks if there are any child nodes.
You may wish to reimplement this method if you reimplement populate(), and you have a quick default for determining whether a node may be expanded (which does not require populating the node).
EventSignal< WMouseEvent > & Wt::WTreeNode::expanded | ( | ) |
Signal emitted when the node is expanded by the user.
|
protected |
The image pack that is used for this tree node (deprecated).
|
virtual |
|
virtual |
Returns if this node may be selected.
|
protected |
Accesses the container widget that holds the label area.
Use this to customize how the label should look like.
WTreeNode* Wt::WTreeNode::parentNode | ( | ) | const |
Returns the parent node.
|
protectedvirtual |
Populates the node dynamically on loading.
Reimplement this method if you want to populate the widget dynamically, as the tree is being browsed and therefore loaded. This is only usefull with LazyLoading or NextLevelLoading strategies.
|
protected |
Returns whether this node has already been populated.
void Wt::WTreeNode::removeChildNode | ( | WTreeNode * | node | ) |
Removes a child node.
The child node itself is not deleted
|
protectedvirtual |
Renders the node to be selected.
The default implementation changes the style class of the labelArea() to "selected".
Signal<bool>& Wt::WTreeNode::selected | ( | ) |
Signal that is emitted when the node is added or removed from the selection
void Wt::WTreeNode::setChildCountPolicy | ( | ChildCountPolicy | policy | ) |
Configures how and when the child count should be displayed.
By default, no child count indication is disabled (this is the behaviour since 2.1.1). Use this method to enable child count indications.
The child count policy is inherited by all children in the tree.
void Wt::WTreeNode::setChildrenDecorated | ( | bool | decorated | ) |
Sets whether this node's children are decorated.
By default, node's children have expand/collapse and other lines to display their linkage and offspring.
By setting decorated
to false
, you can hide the decorations for the node's children.
void Wt::WTreeNode::setImagePack | ( | const std::string & | url | ) |
Sets the image pack for this (sub)tree (deprecated).
void Wt::WTreeNode::setInteractive | ( | bool | interactive | ) |
Sets whether this node is interactive.
Interactive nodes can be clicked upon and will populate a list of children when clicked. By disabling the interactivity, a node will not react to a click event.
void Wt::WTreeNode::setLoadPolicy | ( | LoadPolicy | loadPolicy | ) |
Sets the load policy for this tree.
This may only be set on the root of a tree, and before adding any children.
void Wt::WTreeNode::setNodeVisible | ( | bool | visible | ) |
Sets the visibility of the node itself.
If false
, then the node itself is not displayed, but only its children. This is typically used to hide the root node of a tree.
|
virtual |
Allows this node to be selected.
By default, all nodes may be selected.
Reimplemented from Wt::WCompositeWidget.
|
virtual |
Returns the tree.
By default if this node has no parent the result will be 0.
|
protectedvirtual |
Undo method for doCollapse() stateless implementation.
|
protectedvirtual |
Undo method for doCollapse() stateless implementation.
